Description
- Precise for oxidation stability Test on Oil & Grease
- Useful for Calibration of Thermometer & Thermocouple
- Better Mineral / Cerablanket Insulated to avoid loss of heat & gives better result.
- Polish / Hair Line 304 grade heavy steel sheet duly argon welded to avoid leakage at high Temp. during Test.
- Diffuser plate for the safe handling during test.
- Kanthal 1 special S. S. quality Oil Heaters are fitted to cover oil Bath & gives uniform/ heat Temp. Throughout the Chamber.
- Full feature Digital Temperature Controller Cum Indicator & Microprocessor based PID Temp. Controller can be made (on Customer request)
- Best quality Bi-Metallic capillary Thermostate can be fitted in place of Digital Temp. Controller / PID Controller (On Customer request)
- Best quality 1/20 HP stirrer is fitted on the back side for uniform circulation of liquid & Temp. Bath
Applications
Use for Research & Calibration, Educational Engg. College, Biotech Labs.
Specifications
| Model | JDS 1.22 | JDS 1.22 A | JDS 1.22 B |
| Capacity (L) | 18 Ltrs. | 20 Ltrs. | 12 Ltrs. |
| Interior (mm) | 300 x 250 x 250 mm | 300 x 300 x 250 mm | 250 x 250 x 250 mm |
| Wattage “W” | 2.0 KW | 2.0 KW | 1.5 KW |
| Diffuser Plate/ Shelves | 01 No. | 01 No. | 01 No. |
Dimensions are expressed in (Width x Depth x Height)
Technical Parameters
| Temperature: | Ambient to 250°C |
| Temperature Stability: | +-1°C/ 2°C or better |
| Control Panel: | Mains Indicator Load Indicator Speed Regulator, Temp. Controller |
| Digital Setting: | 1°C |
| Digital Resolution: | 1°C |
| Optional: |
|
| Interior: | Polish/ Hair line S.S. 304 grade As per requirement |
| Power Consumption: | 220/230V AC supply +-10% 50Hz |
| Duty Cycle: | Continuous |
| Housing Material: | CRC/ MS Sheet body duly Powder Coated |
