Description
-
Precise hot Air Drying & Sterilization.
-
Better Mineral / Glasswool / Blanket Insulation keeps the surface of the instruments from being Burnt
-
Silent Hot Air Blower, unique Design of Air Circulation provide throughout uniform air movement & improved Temperature distribution
-
Unique design of Ventilation keep the surface of the instrument from being burnt even when the instrument i.e. Oven Temperature maintained at above 200°C
-
Polish 304 grade S. Steel interior, corrosion resistant long life operation having adjustable shelves to make more space for different height.
-
Kanthal A-1 super quality coil shaped heaters duly embedded / wound on the sides & bottom for better accuracy.
-
Best quality Bi-Metallic Hydraulic capillary Thermostate, full features with Digital Temperature Controller Cum Indicator & Microprocessor Based PID Temperature Controller Cum Indicator having alarm facility (On Customer Request)
Applications
Sterilization & Storage for Pharmaceutical, Agriculture, Medical & food industries, education Institute, Bio-Tech, Laboratory requiring controlled Temperature above ambient
Specifications
Model |
JDS 1.01 |
JDS 1.01 (A) |
JDS 1.01 (B) |
JDS 1.01 (C) |
JDS 1.01 (D) |
JDS 1.01 (E) |
JDS 1.01 (F) |
| Capacity (Ltrs.) | 28 | 45 | 95 | 125 | 224 | 336 | 252 |
| Interior (mm) | 300x300x300 | 300x350x350 | 450x450x450 | 450x450x605 | 605x605x605 | 605x605x900 | 605x450x900 |
| Heater Wattage “W” |
1.0 KW | 1.0 KW | 1.5 KW | 2.0 KW | 2.5 KW | 3.0 KW | 2.5 KW |
| Shelves | 1/2 | 1/2 | 2 | 2 | 2 | 3 | 3 |
Technical Parameters
| Temperature Range: | Ambient to 350°C, Controlled from 100°C – 350°C. |
| Temperature Stability: | +-2°C |
| Housing Material: | CRC/Mild Steel with Powder Coated |
| Duty Cycle: | Continuous |
| Interior: | S. Steel 304 grade heavy gauge to withstand Temp. up to 350°C |
| Insulation: | High Temperature Ceramic Blanket |
| Power Consumption: |
|
